3 Way Brass Ball Valves

Model: T103 L & T103T

Model: T103L & T103T SPECIFICATIONS

3 Way Brass Ball Valve



Maximum Operating Pressure:
1/4” to 2” 400 PSIG @ 100ºF WOG*

Temperature  Range: -30 to 120 ºC*

End Connections: NPT Threaded (Female)
Stem is blowout-proof

Brass body, brass stem, chrome-plated ball, seats and seal are Teflon, handle is made of steel with vinyl covering

   DIMENSIONS (mm)

SIZE

1/2
3/4

d

15
20

L

57
65

H

50
55

W

85
115
